Adet bazlı fiyat
- 1+ adet$9.06
- 10+ adet$8.55
- 100+ adet$8.06
- 500+ adet$7.61
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Kurşunsuz Kodu
- yes
- Contact Currentacmax
- 5A
- Fabrika Tedarik Süresi
- 5 Weeks
- Mechanical Life
- 1,000,000 Cycles
- Throw Configuration
- DPDT, SPDT
- Contact Plating
- Gold, Silver
- Contact Materials
- Silver
- Yayın Yılı
- 2011
- Depth
- 17.8mm
- Contact Ac Max Rating R Load
- 5A@250VAC
- Max Voltage Rating Dc
- 30V
- Contact Function
- ON-(ON)
- Electricallife
- 10,000 Cycles
- Özellikler
- Epoxy Sealed Terminals
- Panel Cutout Dimensions
- Square - 16.20mm2
- Kurşunsuz
- Lead Free
- Max Current Rating
- 5A
- Tip
- Standard
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Withstanding Voltage
- 1500VAC V
- Kılıf / Paket
- 125
- Contact Resistance
- 0.05mOhm
- Circuit
- SPDT
- Body Breadth
- 15.7988 mm
- Çalışma Sıcaklığı
- -20°C~70°C
- Terminal Material
- PHOSPHOR BRONZE
- Montaj Tipi
- Panel Mount, Snap-In
- Montaj
- Panel, Snap in
- Insulation Resistance
- 200000000Ohm
- Terminal
- Solder
- Contact Current Rating
- 5A
- Terminal Stili
- Solder Lug
- Max Voltage Rating Ac
- 250V
- Color Actuatorcap
- Black
- RoHS Durumu
- ROHS3 Compliant
- Uzunluk
- 17.8mm
- Switch Function
- On-Mom
- Housing Material
- Polyamide
- Voltage Rated Ac
- 125V
