Adet bazlı fiyat
- 1+ adet$9.87
- 10+ adet$9.31
- 100+ adet$8.79
- 500+ adet$8.29
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Orientation
- Vertical
- Fabrika Tedarik Süresi
- 11 Weeks
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2002
- Contact Materials
- Copper
- Contact Plating
- Gold
- Throw Configuration
- DPDT, SPDT
- Mechanical Life
- 1,000,000 Cycles
- Panel Cutout Dimensions
- Square - 16.20mm2
- Özellikler
- Epoxy Sealed Terminals
- Electricallife
- 200,000 Cycles
- Contact Function
- ON-(ON)
- Max Voltage Rating Dc
- 28V
- Depth
- 17.8mm
- Kurşunsuz
- Lead Free
- Tip
- Standard
- Max Current Rating
- 100mA
- Contact Resistance
- 0.1mOhm
- Dielectric Withstanding Voltage
- 1500VAC V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Material
- PHOSPHOR BRONZE
- Çalışma Sıcaklığı
- -20°C~70°C
- Body Breadth
- 15.7988 mm
- JESD-609 Kodu
- e4
- Circuit
- SPDT
- Montaj
- Panel, Snap in
- Montaj Tipi
- Panel Mount, Snap-In
- Insulation Resistance
- 200000000Ohm
- Illumination Type
- Illuminated
- Terminal
- Solder
- Color Actuatorcap
- Yellow
- Power Rating
- 400mW
- Terminal Stili
- Solder Lug
- Max Voltage Rating Ac
- 28V
- Uzunluk
- 17.8mm
- RoHS Durumu
- ROHS3 Compliant
- Housing Material
- Polyamide
- Switch Function
- On-Mom
- Actuator Travel
- 2.3114 mm
- Parça Durumu
- Active
