Adet bazlı fiyat
- 1+ adet$10.09
- 10+ adet$9.52
- 100+ adet$8.98
- 500+ adet$8.47
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Tip
- Standard
- Housing Material
- Polyamide
- Switch Function
- On-Mom
- Parça Durumu
- Active
- Ambalaj
- Tray
- Actuator Travel
- 2.3114 mm
- Dielectric Withstanding Voltage
- 1500VAC V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- UB
- Voltage Rated Ac
- 28V
- Contact Resistance
- 0.1mOhm
- Çalışma Sıcaklığı
- -20°C~70°C
- JESD-609 Kodu
- e4
- Body Breadth
- 15.7988 mm
- Terminal Material
- PHOSPHOR BRONZE
- Body Length Or Diameter
- 15.7988mm
- Circuit
- SPDT
- Current Rating Amps
- 0.4VA AC/DC
- Montaj
- Panel, Snap in
- Actuator Type
- Square, Button
- Montaj Tipi
- Panel Mount, Snap-In
- Flammability Rating
- UL94 V-0
- ECCN Kodu
- EAR99
- Voltage Rated Dc
- 28V
- Body Height
- 17.5006mm
- Fabrika Tedarik Süresi
- 11 Weeks
- Insulation Resistance
- 200000000Ohm
- Orientation
- Vertical
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2002
- Throw Configuration
- DPDT, SPDT
- Mechanical Life
- 1,000,000 Cycles
- Terminal
- Solder
- Contact Plating
- Gold
- Electricallife
- 200,000 Cycles
- Contact Function
- ON-(ON)
- Panel Cutout Dimensions
- Square - 16.20mm2
- Özellikler
- Epoxy Sealed Terminals
- Power Rating
- 400mW
- Terminal Stili
- Solder Lug
