Adet bazlı fiyat
- 1+ adet$12.23
- 10+ adet$11.53
- 100+ adet$10.88
- 500+ adet$10.26
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Switch Function
- On-Mom
- Housing Material
- Polyamide
- Tip
- Standard, Illuminated
- Max Current Rating
- 100mA
- Seri
- UB
- Voltage Rated Ac
- 28V
- Illumination Voltage Nominal
- 2.1VDC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Ambalaj
- Tray
- Current Rating Amps
- 0.4VA AC/DC
- Circuit
- SPDT
- Çalışma Sıcaklığı
- -25°C~50°C
- Voltage Rated Dc
- 28V
- Flammability Rating
- UL94 V-0
- Montaj Tipi
- Panel Mount, Snap-In
- Actuator Type
- Square, Button
- Montaj
- Panel, Snap in
- Kurşunsuz Kodu
- yes
- Illumination Type
- Illuminated, LED
- Orientation
- Vertical
- Fabrika Tedarik Süresi
- 11 Weeks
- Terminal
- Solder
- Contact Plating
- Gold
- Mechanical Life
- 1,000,000 Cycles
- Yayın Yılı
- 2009
- Contact Materials
- Copper
- Color Actuatorcap
- Green
- Terminal Stili
- Solder Lug
- Max Voltage Rating Ac
- 28V
- Power Rating
- 400mW
- Depth
- 17.8mm
- Özellikler
- Epoxy Sealed Terminals
- Illumination Type Color
- LED, Green
- Panel Cutout Dimensions
- Square - 16.20mm2
- Max Voltage Rating Dc
- 28V
- Electricallife
- 200,000 Cycles
- Kurşunsuz
- Lead Free
- RoHS Durumu
- ROHS3 Compliant
- Uzunluk
- 17.8mm
