Teknik Özellikler
- Voltage Rated Ac
- 125V
- Number Of Poles Per Deck
- 1
- Kurşunsuz
- Contains Lead
- RoHS Durumu
- ROHS3 Compliant
- Voltage Rated Dc
- 250V
- Terminal
- Screw
- Uzunluk
- 44mm
- Throw Configuration
- 3P, 3P12T, SP11T
- Insulation Resistance
- 200MOhm
- Contact Ac Max Rating R Load
- 6A@250VAC
- Parça Durumu
- Obsolete
- Contact Plating
- Brass, Silver
- Fabrika Tedarik Süresi
- 8 Weeks
- Switch Type
- ROTARY SWITCH
- Montaj
- Panel
- Yayın Yılı
- 2011
- Kurşunsuz Kodu
- yes
- Actuator Finish
- NICKEL
- Contact Materials
- Phosphor Bronze
- Illumination Type
- Illuminated
- Reach Svhc
- No SVHC
- Contact Timing
- Non-Shorting (BBM)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 6A
- Number Of Decks
- 3
- Body Height
- 70.0024mm
- Contact Style
- Non-Shorting
- Depth Behind Panel
- 46.00mm
- Contact Currentacmax
- 6A
- Panel Cutout Dimensions
- Circular - 10.30mm Dia
- Maks. Çalışma Sıcaklığı
- 70°C
- Circuit Per Deck
- SP11T
- Operating Force
- 35gfm
- Index Stops
- Adjustable
- Terminal Kaplaması
- Silver (Ag)
- Seri
- TS
- Pozisyon Sayısı
- 2 ~ 11
- Max Voltage Rating Ac
- 250V
- Actuator Type
- Flatted (6mm Dia)
- Terminal Material
- COPPER
