Adet bazlı fiyat
- 1+ adet$2.56
- 10+ adet$2.42
- 100+ adet$2.28
- 500+ adet$2.15
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Max Current Rating
- 100mA
- Actuator Material
- Polyphenylene Sulfide (PPS)
- Contact Currentdcmax
- 0.014A
- Housing Material
- Bronze
- Reach Svhc
- No SVHC
- Depth
- 7.45mm
- Kılıf / Paket
- SMD/SMT
- Pozisyon Sayısı
- 3
- Insulation Resistance
- 100000000Ohm
- Mechanical Life
- 10,000 Cycles
- JESD-609 Kodu
- e4
- Contact Current Rating
- 100mA
- Orientation
- Horizontal
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Fabrika Tedarik Süresi
- 5 Weeks
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Contact Currentacmax
- 0.014A
- Actuator Length
- 2.00mm
- Çalışma Sıcaklığı
- -25°C~85°C
- Contact Plating
- Gold, Silver
- Actuator Type
- Standard
- Montaj
- Surface Mount
- Dielectric Withstanding Voltage
- 500VAC V
- Voltage Rated Dc
- 28V
- Packing Method
- TR
- Uzunluk
- 10.5mm
- Terminal Stili
- Gull Wing
- Max Voltage Rating Ac
- 28V
- Voltage Rated Ac
- 28V
- Seri
- SS3
- Montaj Tipi
- Surface Mount, Right Angle
- Electricallife
- 10,000 Cycles
- Current Rating Amps
- 0.4VA AC/DC
- Contact Dc Max Rating R Load
- .014A@28VDC
- Switch Function
- On-On
- HTS Kodu
- 8536.50.90.50
- Terminal
- Gull Wing
- Contact Ac Max Rating R Load
- .014A@28VAC
- Contact Timing
- Shorting (MBB)
