Adet bazlı fiyat
- 1+ adet$4.12
- 10+ adet$3.88
- 100+ adet$3.66
- 500+ adet$3.46
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj Tipi
- Through Hole
- Voltage Rated Dc
- 28V
- Switch Type
- SLIDE SWITCH
- Seri
- SS
- Contact Plating
- Gold, Silver
- RoHS Durumu
- ROHS3 Compliant
- Max Voltage Rating Ac
- 28V
- Fabrika Tedarik Süresi
- 9 Weeks
- Contact Materials
- Phosphor Bronze
- Yayın Yılı
- 2010
- Circuit
- DPDT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Timing
- Shorting (MBB)
- Mechanical Life
- 10,000 Cycles
- Electricallife
- 10,000 Cycles
- Parça Durumu
- Active
- Contact Dc Max Rating R Load
- .014A@28VDC
- HTS Kodu
- 8536.50.90.50
- Max Voltage Rating Dc
- 28V
- Voltage Rated Ac
- 28V
- Illumination Type
- Non-Illuminated
- ECCN Kodu
- EAR99
- Current Rating Amps
- 0.4VA AC/DC
- Max Current Rating
- 100mA
- Depth
- 6.54mm
- Actuator Type
- Standard
- Contact Ac Max Rating R Load
- .014A@28VAC
- Kurşunsuz
- Lead Free
- Body Height
- 4.5mm
- Contact Style
- Shorting
- Terminal
- PC Pins
- Housing Material
- Resin
- Contact Currentdcmax
- 0.014A
- JESD-609 Kodu
- e4
- Montaj
- Through Hole
- Uzunluk
- 10.2mm
- Kurşunsuz Kodu
- yes
- Actuator Material
- Polyamide (PA), Nylon
- Ambalaj
- Tray
- Terminal Stili
- PC Pin
