Adet bazlı fiyat
- 1+ adet$2.75
- 10+ adet$2.59
- 100+ adet$2.44
- 500+ adet$2.31
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Illumination Type
- Non-Illuminated
- Kurşunsuz Kodu
- yes
- Orientation
- Horizontal
- Switch Function
- On-On
- Contact Currentdcmax
- 0.014A
- Flammability Rating
- UL94 V-0
- Mechanical Life
- 10,000 Cycles
- Yayın Yılı
- 2010
- Current Rating Amps
- 0.4VA AC/DC
- Voltage Rated Ac
- 28V
- Actuator Material
- Polyamide (PA), Nylon
- Contact Style
- Shorting
- Actuator Type
- Standard
- Montaj
- Through Hole
- Kurşunsuz
- Lead Free
- Seri
- SS
- Max Current Rating
- 100mA
- Contact Plating
- Gold, Silver
- JESD-609 Kodu
- e4
- Electricallife
- 10,000 Cycles
- Fabrika Tedarik Süresi
- 9 Weeks
- Housing Material
- Resin
- Switch Travel
- 2.00mm
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Uzunluk
- 10.2mm
- Terminal Stili
- PC Pin
- Montaj Tipi
- Through Hole, Right Angle
- Max Voltage Rating Ac
- 28V
- Contact Materials
- Phosphor Bronze
- Ambalaj
- Tray
- Contact Current Rating
- 100mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reach Svhc
- No SVHC
- ECCN Kodu
- EAR99
- Actuator Length
- 2.50mm
- Voltage Rated Dc
- 28V
- Contact Timing
- Shorting (MBB)
- Contact Finish
- Gold
- Contact Dc Max Rating R Load
- .014A@28VDC
