Adet bazlı fiyat
- 1+ adet$7.76
- 10+ adet$7.32
- 100+ adet$6.91
- 500+ adet$6.52
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Kurşunsuz
- Contains Lead
- Solderability
- WAVE
- Terminal Stili
- Gull Wing
- Actuator Type
- Rotary with Shaft
- Additional Feature
- REAL CODED
- Contact Finish
- Gold
- Electricallife
- 20,000 Steps
- Parça Durumu
- Active
- Terminal
- Gull Wing
- Akım Değeri
- 100mA
- Dielectric Withstanding Voltage
- 250VAC V
- Montaj
- Surface Mount
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- ND3
- Switch Type
- ROTARY CODED SWITCH
- Body Material
- Polyamide (PA), Nylon, Glass Filled
- JESD-609 Kodu
- e4
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Contact Timing
- BREAK-BEFORE-MAKE
- Contact Resistance
- 0.03mOhm
- Housing Material
- GLASS FILLED REINFORCED NYLON
- Pitch
- 0.100 2.54mm Full
- Uzunluk
- 0.320 8.13mm
- Body Breadth
- 7.9248 mm
- Contact Materials
- Beryllium Copper
- Montaj Tipi
- Surface Mount
- Nominal Gerilim
- 5VDC
- Height Above Board
- 0.346 8.80mm
- Washable
- Yes
- Özellikler
- Epoxy Sealed Terminals
- Contact Currentdcmax
- 0.1A
- Fabrika Tedarik Süresi
- 10 Weeks
- Mechanical Life
- 20,000 Steps
- RoHS Durumu
- ROHS3 Compliant
- Pozisyon Sayısı
- 10
- Contact Function
- ON-ON
- Circuit
- BCD
- Yayın Yılı
- 2010
- Contact Voltagedcmax
- 5V
- Washability
- SOLVENT
