Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Finish
- Gold
- Additional Feature
- REAL CODED
- Solderability
- WAVE
- Terminal Stili
- Gull Wing
- Actuator Type
- Rotary for Tool
- Kurşunsuz
- Lead Free
- Illumination Type
- Illuminated
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- ND3
- Leadbase Style
- Gull Wing
- Depth
- 7.9mm
- Terminal
- Gull Wing
- Parça Durumu
- Active
- Electricallife
- 20,000 Steps
- Akım Değeri
- 100mA
- Montaj
- Surface Mount
- Dielectric Withstanding Voltage
- 250VAC V
- Max Current Rating
- 100mA
- Insulation Materials
- GLASS FILLED POLYAMIDE
- Contact Timing
- BREAK-BEFORE-MAKE
- Body Material
- Polyamide (PA), Nylon, Glass Filled
- Number Of Poles
- 1
- JESD-609 Kodu
- e4
- Switch Type
- ROTARY CODED SWITCH
- Orientation
- Right Angle
- Pitch
- 0.050 1.27mm Half
- Uzunluk
- 0.320 8.13mm
- Housing Material
- GLASS FILLED REINFORCED NYLON
- ECCN Kodu
- EAR99
- Contact Resistance
- 0.03mOhm
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 10 Weeks
- HTS Kodu
- 8536.50.90.20
- Mechanical Life
- 20,000 Steps
- Washable
- Yes
- Özellikler
- Epoxy Sealed Terminals
- Contact Materials
- Beryllium Copper
- Body Breadth
- 8.0264 mm
- Montaj Tipi
- Surface Mount, Right Angle
- Height Above Board
- 0.316 8.03mm
