Teknik Özellikler
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Contact Materials
- Copper
- Orientation
- Vertical
- Pozisyon Sayısı
- 3
- Body Height
- 17.1958mm
- Circuit
- DPDT
- Mechanical Life
- 100,000 Cycles
- Body Breadth
- 11.4046 mm
- Switch Travel
- 3.50mm
- Contact Finish
- Gold
- Yayın Yılı
- 2015
- Electricallife
- 50,000 Cycles
- Fabrika Tedarik Süresi
- 7 Weeks
- Voltage Rated Ac
- 28V
- Montaj
- Panel
- Terminal
- Solder
- Actuator Type
- Standard
- Contact Resistance
- 0.02mOhm
- Solderability
- WAVE
- Montaj Tipi
- Panel Mount
- Contact Timing
- Non-Shorting (BBM)
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Terminal Stili
- Solder Lug
- Switch Type
- SLIDE SWITCH
- REACH Uyumluluk Kodu
- not_compliant
- Illumination Type
- Non-Illuminated
- Flammability Rating
- UL94 V-0
- Insulation Resistance
- 1000000000Ohm
- Switch Function
- On-Off-On
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Current Rating Amps
- 0.4VA AC/DC
- Ambalaj
- Bulk
- RoHS Durumu
- ROHS3 Compliant
- Housing Material
- STAINLESS STEEL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Withstanding Voltage
- 1500VAC V
- Seri
- MS
- Özellikler
- Epoxy Sealed Terminals
- Body Length Or Diameter
- 12.7mm
- Çalışma Sıcaklığı
- -30°C~85°C
