Adet bazlı fiyat
- 1+ adet$7.11
- 10+ adet$6.70
- 100+ adet$6.32
- 500+ adet$5.97
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 7 Weeks
- Electricallife
- 25,000 Cycles
- Pcb Hole Count
- 6
- Contact Current Rating
- 6A
- Voltage Rated Ac
- 125V
- Montaj
- Through Hole
- Body Height
- 19.05mm
- Body Breadth
- 11.4046 mm
- Switch Travel
- 3.50mm
- Orientation
- Vertical
- Pozisyon Sayısı
- 3
- Contact Materials
- Silver Alloy
- REACH Uyumluluk Kodu
- not_compliant
- Terminal Stili
- PC Pin
- Switch Type
- SLIDE SWITCH
- Reach Svhc
- No SVHC
- Montaj Tipi
- Through Hole
- Ambalaj
- Bulk
- Switch Function
- On-Off-On
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Insulation Resistance
- 1000000000Ohm
- Current Rating Amps
- 6A AC
- Contact Ac Max Rating R Load
- 3A@250VAC
- Terminal Material
- COPPER ALLOY
- Length Termination
- 0.25 inch
- Dielectric Withstanding Voltage
- 1500VAC V
- Seri
- MS
- Özellikler
- Epoxy Sealed Terminals
- Contact Voltageacmax
- 250V
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2000
- Terminal
- PC Pin
- Circuit
- DPDT
- Mechanical Life
- 100,000 Cycles
- Contact Finish
- Silver
- ECCN Kodu
- EAR99
- Contact Style
- Non-Shorting
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Contact Timing
- Non-Shorting (BBM)
