Adet bazlı fiyat
- 1+ adet$7.25
- 10+ adet$6.84
- 100+ adet$6.46
- 500+ adet$6.09
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Çalışma Sıcaklığı
- -30°C~85°C
- Parça Durumu
- Active
- Body Length Or Diameter
- 12.7mm
- Length Termination
- 0.25 inch
- Kurşunsuz Kodu
- yes
- Actuator Length
- 5.10mm
- Housing Material
- STAINLESS STEEL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Özellikler
- Epoxy Sealed Terminals
- Seri
- MS
- Kurşunsuz
- Lead Free
- Dielectric Withstanding Voltage
- 1500VAC V
- Ambalaj
- Bulk
- Flammability Rating
- UL94 V-0
- Illumination Type
- Non-Illuminated
- Current Rating Amps
- 0.4VA AC/DC
- Insulation Resistance
- 1000000000Ohm
- Switch Function
- On-Off-On
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Switch Type
- SLIDE SWITCH
- Contact Timing
- Non-Shorting (BBM)
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Terminal Stili
- PC Pin
- Voltage Rated Dc
- 28V
- REACH Uyumluluk Kodu
- not_compliant
- Contact Resistance
- 0.02mOhm
- Actuator Type
- Standard
- Montaj Tipi
- Through Hole
- Solderability
- WAVE
- Contact Finish
- Gold
- Switch Travel
- 3.50mm
- Body Breadth
- 11.4046 mm
- Mechanical Life
- 100,000 Cycles
- Body Height
- 19.05mm
- Circuit
- DPDT
- Terminal
- PC Pin
- Pcb Hole Count
- 6
- Montaj
- Through Hole
- Voltage Rated Ac
- 28V
