Teknik Özellikler
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- REACH Uyumluluk Kodu
- not_compliant
- Switch Type
- SLIDE SWITCH
- Terminal Stili
- PC Pin
- Reach Svhc
- No SVHC
- Orientation
- Vertical
- Pozisyon Sayısı
- 2
- Contact Materials
- Silver Alloy
- Electricallife
- 25,000 Cycles
- Fabrika Tedarik Süresi
- 7 Weeks
- Contact Current Rating
- 6A
- Voltage Rated Ac
- 125V
- Montaj
- Through Hole, Vertical
- Pcb Hole Count
- 8
- Body Height
- 26.035mm
- Switch Travel
- 2.20mm
- Body Breadth
- 11.4046 mm
- Dielectric Withstanding Voltage
- 1500VAC V
- Özellikler
- Epoxy Sealed Terminals
- Contact Voltageacmax
- 250V
- Seri
- MS
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Length Termination
- 0.106 inch
- Terminal Material
- COPPER ALLOY
- Current Rating Amps
- 6A AC
- Contact Ac Max Rating R Load
- 3A@250VAC
- Switch Function
- On-On
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Insulation Resistance
- 1000000000Ohm
- Ambalaj
- Bulk
- Solderability
- WAVE
- Actuator Type
- Standard
- Contact Resistance
- 0.01mOhm
- Akım Değeri
- 6A
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Contact Timing
- Non-Shorting (BBM)
- HTS Kodu
- 8536.50.90.50
- ECCN Kodu
- EAR99
- Contact Style
- Non-Shorting
