Teknik Özellikler
- Circuit
- DPDT
- Body Height
- 17.1958mm
- Mechanical Life
- 100,000 Cycles
- Body Breadth
- 11.4046 mm
- Contact Finish
- Gold
- Switch Travel
- 2.20mm
- Yayın Yılı
- 2015
- Electricallife
- 50,000 Cycles
- Fabrika Tedarik Süresi
- 7 Weeks
- Voltage Rated Ac
- 28V
- Montaj
- Panel
- Terminal
- Solder
- Contact Style
- Non-Shorting
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Contact Materials
- Copper
- Pozisyon Sayısı
- 2
- Terminal Stili
- Solder Lug
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Contact Timing
- Non-Shorting (BBM)
- Switch Type
- SLIDE SWITCH
- REACH Uyumluluk Kodu
- not_compliant
- Voltage Rated Dc
- 28V
- Actuator Type
- Standard
- Contact Resistance
- 0.02mOhm
- Solderability
- WAVE
- Montaj Tipi
- Panel Mount
- Ambalaj
- Bulk
- Illumination Type
- Non-Illuminated
- Flammability Rating
- UL94 V-0
- Insulation Resistance
- 1000000000Ohm
- Switch Function
- On-On
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Current Rating Amps
- 0.4VA AC/DC
- Body Length Or Diameter
- 12.7mm
- Çalışma Sıcaklığı
- -30°C~85°C
- Parça Durumu
- Active
- Actuator Length
- 5.10mm
- Length Termination
- 0.177 inch
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
