Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ambalaj
- Bulk
- Illumination Type
- Non-Illuminated
- Contact Currentacmax
- 6A
- Flammability Rating
- UL94 V-0
- Contact Ac Max Rating R Load
- 6A@125VAC
- Current Rating Amps
- 6A AC
- Insulation Resistance
- 1000000000Ohm
- Switch Function
- On-On
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Body Length Or Diameter
- 15.7988mm
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -30°C~85°C
- Actuator Length
- 5.10mm
- Kurşunsuz Kodu
- yes
- Length Termination
- 0.264 inch
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Epoxy Sealed Terminals
- Seri
- MS
- Body Height
- 7.5946mm
- Circuit
- DPDT
- Contact Finish
- Silver
- Switch Travel
- 2.20mm
- Mechanical Life
- 100,000 Cycles
- Body Breadth
- 11.9126 mm
- Fabrika Tedarik Süresi
- 9 Weeks
- Electricallife
- 25,000 Cycles
- Yayın Yılı
- 2011
- Contact Current Rating
- 3A
- Voltage Rated Ac
- 125V
- Montaj
- Through Hole
- Contact Materials
- Silver Alloy
- Contact Timing
- Non-Shorting (BBM)
- Terminal Stili
- PC Pin
- Actuator Type
- Standard
- Contact Resistance
- 0.01mOhm
- Solderability
- WAVE
- Montaj Tipi
- Through Hole
