Teknik Özellikler
- Contact Materials
- Copper
- Pozisyon Sayısı
- 2
- Body Height
- 22.8346mm
- Switch Travel
- 2.20mm
- Body Breadth
- 11.4046 mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Electricallife
- 50,000 Cycles
- Voltage Rated Ac
- 28V
- Montaj
- Through Hole
- Pcb Hole Count
- 8
- Montaj Tipi
- Through Hole, Right Angle
- Switch Type
- SLIDE SWITCH
- Terminal Stili
- PC Pin
- REACH Uyumluluk Kodu
- not_compliant
- Current Rating Amps
- 0.4VA AC/DC
- Switch Function
- On-On
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Insulation Resistance
- 1000000000Ohm
- Ambalaj
- Bulk
- RoHS Durumu
- ROHS3 Compliant
- Depth
- 22.85mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 100mA
- Dielectric Withstanding Voltage
- 1500VAC V
- Özellikler
- Epoxy Sealed Terminals
- Seri
- MS
- Contact Style
- Non-Shorting
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Circuit
- DPDT
- Max Voltage Rating Ac
- 28V
- Contact Finish
- Gold
- Mechanical Life
- 100,000 Cycles
- Yayın Yılı
- 2015
- Terminal
- PC Pin
- Actuator Type
- Standard
- Contact Resistance
- 0.02mOhm
- Uzunluk
- 13.6mm
- Solderability
- WAVE
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Contact Timing
- Non-Shorting (BBM)
