Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Illumination Type
- Non-Illuminated
- Flammability Rating
- UL94 V-0
- Contact Currentacmax
- 6A
- Max Voltage Rating Dc
- 28V
- Current Rating Amps
- 6A AC
- Contact Ac Max Rating R Load
- 6A@125VAC
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Switch Function
- On-On
- Insulation Resistance
- 1000000000Ohm
- Ambalaj
- Tray
- RoHS Durumu
- ROHS3 Compliant
- Depth
- 11.9mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 6A
- Kurşunsuz
- Lead Free
- Özellikler
- Epoxy Sealed Terminals
- Seri
- MS
- Çalışma Sıcaklığı
- -30°C~85°C
- Parça Durumu
- Active
- Actuator Length
- 5.10mm
- Kurşunsuz Kodu
- yes
- Contact Materials
- Silver Alloy
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- ECCN Kodu
- EAR99
- Circuit
- DPDT
- Body Height
- 7.5946mm
- Switch Travel
- 2.20mm
- Contact Finish
- Gold
- Max Voltage Rating Ac
- 250V
- Body Breadth
- 11.9126 mm
- Mechanical Life
- 100,000 Cycles
- Fabrika Tedarik Süresi
- 7 Weeks
- Electricallife
- 25,000 Cycles
- Terminal
- PC Pins
- Contact Current Rating
- 6A
- Montaj
- Through Hole
- Voltage Rated Ac
- 125V
- Actuator Type
- Standard
- Uzunluk
- 16.2mm
- Contact Resistance
- 0.01mOhm
