Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Yükseklik
- 14.25mm
- Max Voltage Rating Dc
- 28V
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -30°C~85°C
- Actuator Length
- 5.10mm
- Kurşunsuz Kodu
- yes
- Housing Material
- STAINLESS STEEL
- Kurşunsuz
- Lead Free
- Circuit
- DPDT
- Max Voltage Rating Ac
- 28V
- Contact Finish
- Gold
- Mechanical Life
- 100,000 Cycles
- Yayın Yılı
- 2015
- Terminal
- PC Pins
- Contact Style
- Non-Shorting
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- ECCN Kodu
- EAR99
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Contact Timing
- Non-Shorting (BBM)
- HTS Kodu
- 8536.50.90.50
- Voltage Rated Dc
- 28V
- Actuator Type
- Standard
- Contact Resistance
- 20mOhm
- Uzunluk
- 12.7mm
- Contact Plating
- Gold, Silver
- Solderability
- WAVE
- Ambalaj
- Bulk
- Current Rating Amps
- 0.4VA AC/DC
- Switch Function
- On-On
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Insulation Resistance
- 1000000000Ohm
- RoHS Durumu
- ROHS3 Compliant
- Depth
- 11.9mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 100mA
- Dielectric Withstanding Voltage
- 1500VAC V
- Özellikler
- Epoxy Sealed Terminals
- Seri
- MS
- Switch Travel
- 2.20mm
- Body Breadth
- 11.4046 mm
