Teknik Özellikler
- Illumination Type
- Non-Illuminated
- Flammability Rating
- UL94 V-0
- Contact Currentacmax
- 3A
- Housing Material
- STAINLESS STEEL
- Kurşunsuz
- Contains Lead
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -30°C~85°C
- Actuator Length
- 5.10mm
- Kurşunsuz Kodu
- yes
- Contact Style
- Non-Shorting
- ECCN Kodu
- EAR99
- Circuit
- SP3T
- Contact Finish
- Silver
- Max Voltage Rating Ac
- 250V
- Mechanical Life
- 100,000 Cycles
- Yayın Yılı
- 2016
- Terminal
- PC Pin
- Actuator Type
- Standard
- Contact Resistance
- 0.01mOhm
- Uzunluk
- 12.7mm
- Solderability
- WAVE
- Akım Değeri
- 6A
- Contact Timing
- Non-Shorting (BBM)
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- HTS Kodu
- 8536.50.90.50
- Current Rating Amps
- 6A AC
- Contact Ac Max Rating R Load
- 3A@250VAC
- Insulation Resistance
- 1000000000Ohm
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Switch Function
- On-On-On
- Ambalaj
- Tray
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 7.1mm
- Max Current Rating
- 6A
- Dielectric Withstanding Voltage
- 1500VAC V
- Özellikler
- Jumper needed to achieve triple throw
- Seri
- MS
- Terminal Material
- COPPER ALLOY
- Contact Materials
- Silver Alloy
