Teknik Özellikler
- Montaj Tipi
- Through Hole
- Sealing
- EPOXY
- REACH Uyumluluk Kodu
- not_compliant
- Switch Type
- SLIDE SWITCH
- Terminal Stili
- PC Pin
- Pozisyon Sayısı
- 3
- Contact Materials
- Silver Alloy
- Voltage Rated Ac
- 125V
- Montaj
- Through Hole
- Pcb Hole Count
- 10
- Fabrika Tedarik Süresi
- 7 Weeks
- Electricallife
- 25,000 Cycles
- Switch Travel
- 3.50mm
- Body Breadth
- 11.9126 mm
- Body Height
- 19.7612mm
- Özellikler
- Jumper needed to achieve triple throw
- Seri
- MS
- Dielectric Withstanding Voltage
- 1500VAC V
- Depth
- 7.1mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 6A
- RoHS Durumu
- ROHS3 Compliant
- Terminal Material
- COPPER ALLOY
- Current Rating Amps
- 6A AC
- Contact Ac Max Rating R Load
- 3A@250VAC
- Insulation Resistance
- 1000000000Ohm
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Switch Function
- On-On-On
- Ambalaj
- Tray
- Solderability
- WAVE
- Contact Resistance
- 0.01mOhm
- Uzunluk
- 16.2mm
- Actuator Type
- Standard
- Akım Değeri
- 6A
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Contact Timing
- Non-Shorting (BBM)
- Contact Style
- Non-Shorting
- Terminal
- PC Pins
- Max Voltage Rating Ac
- 250V
- Contact Finish
- Silver
