Adet bazlı fiyat
- 1+ adet$7.87
- 10+ adet$7.42
- 100+ adet$7.00
- 500+ adet$6.60
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Style
- Non-Shorting
- Terminal
- PC Pin
- Electricallife
- 50,000 Cycles
- Mechanical Life
- 100,000 Cycles
- Montaj Tipi
- Through Hole, Right Angle
- Solderability
- WAVE
- Contact Finish
- Gold
- Voltage Rated Dc
- 28V
- Depth
- 15.87mm
- Çalışma Sıcaklığı
- -30°C~85°C
- Max Current Rating
- 100mA
- Actuator Length
- 5.10mm
- Terminal Stili
- PC Pin
- Yayın Yılı
- 2015
- Switch Type
- SLIDE SWITCH
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Max Voltage Rating Ac
- 28V
- Body Breadth
- 6.604 mm
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Kurşunsuz Kodu
- yes
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Parça Durumu
- Active
- Contact Timing
- Non-Shorting (BBM)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pcb Hole Count
- 5
- Contact Resistance
- 0.02mOhm
- Dielectric Withstanding Voltage
- 1500VAC V
- Max Voltage Rating Dc
- 28V
- Ambalaj
- Tray
- Kurşunsuz
- Contains Lead
- Body Height
- 15.8496mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Switch Travel
- 3.50mm
- Seri
- MS
- Montaj
- Through Hole
- Pozisyon Sayısı
- 3
- Contact Materials
- Copper
- Current Rating Amps
- 0.4VA AC/DC
- Circuit
- SPDT
- Voltage Rated Ac
- 28V
