Teknik Özellikler
- Terminal
- PC Pins
- Contact Finish
- Gold
- Max Current Rating
- 100mA
- Depth
- 7.1mm
- Çalışma Sıcaklığı
- -30°C~85°C
- Terminal Stili
- PC Pin
- Actuator Length
- 5.10mm
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Switch Type
- SLIDE SWITCH
- Yayın Yılı
- 2014
- Body Material
- Glass fibre, Polyester
- Body Breadth
- 6.604 mm
- Max Voltage Rating Ac
- 28V
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Contact Resistance
- 0.02mOhm
- Max Voltage Rating Dc
- 28V
- Pcb Hole Count
- 3
- Akım Değeri
- 400mA
- Fabrika Tedarik Süresi
- 7 Weeks
- Kurşunsuz
- Lead Free
- Switch Travel
- 3.50mm
- Montaj
- PCB, Through Hole
- Voltage Rated Ac
- 28V
- Current Rating Amps
- 0.4VA AC/DC
- Contact Materials
- Copper
- RoHS Durumu
- ROHS3 Compliant
- Switch Function
- On-Off-On
- Housing Material
- STAINLESS STEEL
- Insulation Resistance
- 1GOhm
- Mechanical Life
- 100,000 Cycles
- Electricallife
- 50,000 Cycles
- Contact Style
- Non-Shorting
- Illumination Type
- Non-Illuminated
- Montaj Tipi
- Through Hole
- Solderability
- WAVE
- Voltage Rated Dc
- 28V
- Contact Timing
- Non-Shorting (BBM)
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
