Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pozisyon Sayısı
- 3
- ECCN Kodu
- EAR99
- Contact Current Rating
- 100mA
- Circuit
- SPDT
- Actuator Type
- Standard
- Özellikler
- Epoxy Sealed Terminals
- Ambalaj
- Tray
- Reach Svhc
- No SVHC
- Body Height
- 16.002mm
- Orientation
- Vertical
- Seri
- MS
- Flammability Rating
- UL94 V-0
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Contact Timing
- Non-Shorting (BBM)
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Style
- Non-Shorting
- Mechanical Life
- 100,000 Cycles
- Electricallife
- 50,000 Cycles
- Solderability
- WAVE
- Montaj Tipi
- Panel Mount
- Illumination Type
- Non-Illuminated
- Voltage Rated Dc
- 28V
- Current Rating Amps
- 0.4VA AC/DC
- Contact Materials
- Copper
- Voltage Rated Ac
- 28V
- Length Termination
- 0.177 inch
- Insulation Resistance
- 1000000000Ohm
- Housing Material
- STAINLESS STEEL
- Switch Function
- On-Off-On
- RoHS Durumu
- ROHS3 Compliant
- HTS Kodu
- 8536.50.90.50
- Fabrika Tedarik Süresi
- 9 Weeks
- Kurşunsuz
- Lead Free
- Switch Travel
- 3.50mm
- Montaj
- Panel
- Yayın Yılı
- 2015
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Switch Type
- SLIDE SWITCH
- Body Breadth
- 6.604 mm
