Adet bazlı fiyat
- 1+ adet$6.22
- 10+ adet$5.87
- 100+ adet$5.54
- 500+ adet$5.22
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Switch Type
- SLIDE SWITCH
- Yayın Yılı
- 2016
- Body Breadth
- 6.604 mm
- Max Voltage Rating Ac
- 250V
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Contact Currentacmax
- 3A
- Contact Resistance
- 0.01mOhm
- Dielectric Withstanding Voltage
- 1500VAC V
- Pcb Hole Count
- 5
- Terminal
- PC Pins
- Contact Finish
- Silver
- Max Current Rating
- 6A
- Depth
- 23.48mm
- Çalışma Sıcaklığı
- -30°C~85°C
- Actuator Length
- 5.10mm
- Terminal Stili
- PC Pin
- Voltage Rated Ac
- 125V
- Terminal Material
- COPPER ALLOY
- Current Rating Amps
- 6A AC
- Contact Materials
- Silver Alloy
- Switch Function
- On-On
- RoHS Durumu
- ROHS3 Compliant
- Housing Material
- STAINLESS STEEL
- Insulation Resistance
- 1000000000Ohm
- Fabrika Tedarik Süresi
- 5 Weeks
- Akım Değeri
- 6A
- Kurşunsuz
- Lead Free
- HTS Kodu
- 8536.50.90.50
- Switch Travel
- 2.20mm
- Montaj
- Through Hole, Vertical
- Contact Timing
- Non-Shorting (BBM)
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mechanical Life
- 100,000 Cycles
- Electricallife
- 25,000 Cycles
- Contact Style
- Non-Shorting
- Solderability
- WAVE
- Montaj Tipi
- Through Hole, Right Angle, Vertical
