Teknik Özellikler
- Uzunluk
- 7.1mm
- Özellikler
- Epoxy Sealed Terminals
- Actuator Type
- Standard
- Pozisyon Sayısı
- 2
- Circuit
- SPDT
- Contact Current Rating
- 100mA
- ECCN Kodu
- EAR99
- Seri
- MS
- Orientation
- Vertical
- Body Height
- 12.7mm
- Ambalaj
- Bulk
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Contact Dc Max Rating R Load
- .014A@28VDC
- Contact Timing
- Non-Shorting (BBM)
- Voltage Rated Dc
- 28V
- Contact Ac Max Rating R Load
- .014A@28VAC
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- Solderability
- WAVE
- Switching Voltage
- 28V
- Contact Style
- Non-Shorting
- Electricallife
- 50,000 Cycles
- Contact Currentdcmax
- 0.014A
- Mechanical Life
- 100,000 Cycles
- Insulation Resistance
- 1000000000Ohm
- Housing Material
- STAINLESS STEEL
- RoHS Durumu
- ROHS3 Compliant
- Switch Function
- On-On
- Contact Materials
- Copper
- Current Rating Amps
- 0.4VA AC/DC
- Voltage Rated Ac
- 28V
- Montaj
- Through Hole, Vertical
- Switch Travel
- 2.20mm
- Sealing
- DUST PROOF; MOISTURE PROOF
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 5 Weeks
- Pcb Hole Count
- 5
- Contact Resistance
- 0.02mOhm
