Teknik Özellikler
- Length Termination
- 0.126 inch
- Özellikler
- Epoxy Sealed Terminals
- Insulation Resistance
- 1000000000Ohm
- Housing Material
- STAINLESS STEEL
- Switch Function
- On-On
- RoHS Durumu
- ROHS3 Compliant
- Current Rating Amps
- 6A AC
- Pozisyon Sayısı
- 2
- Contact Materials
- Silver Alloy
- Circuit
- SPDT
- Voltage Rated Ac
- 125V
- Terminal Material
- COPPER ALLOY
- Actuator Type
- Standard
- Orientation
- Right Angle
- Switch Travel
- 2.20mm
- Seri
- MS
- Montaj
- Through Hole
- Ambalaj
- Tray
- Body Height
- 15.8496mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Kurşunsuz
- Contains Lead
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Contact Timing
- Non-Shorting (BBM)
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Pcb Hole Count
- 5
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Resistance
- 0.02mOhm
- Dielectric Withstanding Voltage
- 1500VAC V
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Switch Type
- SLIDE SWITCH
- Body Breadth
- 6.604 mm
- Çalışma Sıcaklığı
- -30°C~85°C
- Actuator Length
- 5.10mm
- Terminal Stili
- PC Pin
- Mechanical Life
- 100,000 Cycles
- Terminal
- PC Pin
- Electricallife
- 25,000 Cycles
- Body Length Or Diameter
- 12.7mm
