Adet bazlı fiyat
- 1+ adet$6.10
- 10+ adet$5.75
- 100+ adet$5.43
- 500+ adet$5.12
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Depth
- 7.1mm
- Çalışma Sıcaklığı
- -30°C~85°C
- Max Current Rating
- 6A
- Terminal Stili
- PC Pin
- Actuator Length
- 5.10mm
- Terminal
- PC Pin
- Contact Finish
- Gold
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Pcb Hole Count
- 3
- Contact Resistance
- 0.02mOhm
- Dielectric Withstanding Voltage
- 1500VAC V
- Max Voltage Rating Dc
- 28V
- Yayın Yılı
- 2000
- Actuator Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Switch Type
- SLIDE SWITCH
- Body Breadth
- 6.604 mm
- Max Voltage Rating Ac
- 250V
- Switch Travel
- 2.20mm
- Montaj
- Through Hole
- HTS Kodu
- 8536.50.90.50
- Akım Değeri
- 6A
- Fabrika Tedarik Süresi
- 5 Weeks
- Kurşunsuz
- Lead Free
- Housing Material
- STAINLESS STEEL
- Insulation Resistance
- 1000000000Ohm
- RoHS Durumu
- ROHS3 Compliant
- Switch Function
- On-On
- Current Rating Amps
- 6A AC
- Contact Materials
- Silver Alloy
- Terminal Material
- COPPER ALLOY
- Voltage Rated Ac
- 125V
- Contact Style
- Non-Shorting
- Mechanical Life
- 100,000 Cycles
- Electricallife
- 25,000 Cycles
- Solderability
- WAVE
- Montaj Tipi
- Through Hole
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Contact Timing
- Non-Shorting (BBM)
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
