Adet bazlı fiyat
- 1+ adet$7.72
- 10+ adet$7.28
- 100+ adet$6.87
- 500+ adet$6.48
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Materials
- Phosphor Bronze
- Voltage Rated Dc
- 28V
- Uzunluk
- 12.6mm
- Max Voltage Rating Dc
- 28V
- Actuator Length
- 13.00mm
- Voltage Rated Ac
- 28V
- Terminal Stili
- PC Pin
- Operating Force
- 0.510 ~ 2.039gfm
- Özellikler
- Process Sealed
- Contact Timing
- Non-Shorting (BBM)
- Akım Değeri
- 100mA
- Montaj Tipi
- Panel Mount, Through Hole
- Panel Cutout Dimensions
- Circular - 6.35mm Dia
- Max Current Rating
- 100mA
- Contact Style
- Non-Shorting
- Illumination Type
- Illuminated
- Maks. Çalışma Sıcaklığı
- 70°C
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Renk
- Black
- Actuator Material
- Brass
- Terminal
- PC Pins
- Circuit Per Deck
- SP12T
- Contact Resistance
- 50mOhm
- ECCN Kodu
- EAR99
- Montaj
- Panel, Through Hole
- Index Angle
- 30 °
- Depth
- 12.6mm
- Switch Type
- ROTARY SWITCH
- Throw Configuration
- SP, SP11T, SP12T
- Current Rating Amps
- 0.4VA AC/DC
- Index Stops
- Adjustable
- Pozisyon Sayısı
- 2 ~ 12
- Yayın Yılı
- 2006
- Max Voltage Rating Ac
- 28V
- RoHS Durumu
- ROHS3 Compliant
- Reach Svhc
- No SVHC
- Housing Material
- Polyamide
- Actuator Type
- Knob
- Fabrika Tedarik Süresi
- 9 Weeks
