Adet bazlı fiyat
- 1+ adet$16.16
- 10+ adet$15.24
- 100+ adet$14.38
- 500+ adet$13.57
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Yayın Yılı
- 2010
- Contact Timing
- Non-Shorting (BBM)
- Kurşunsuz Kodu
- yes
- Voltage Rated Dc
- 28V
- Contact Finish
- Gold
- Terminal Stili
- PC Pin
- Index Stops
- Fixed
- Orientation
- Vertical
- Voltage Rated Ac
- 28V
- Seri
- MRB
- Terminal Kaplaması
- Tin (Sn)
- ECCN Kodu
- EAR99
- Contact Materials
- Beryllium Copper
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Panel, Through Hole
- Switch Type
- ROTARY SWITCH
- Montaj Tipi
- Panel Mount, Through Hole
- Fabrika Tedarik Süresi
- 9 Weeks
- Number Of Decks
- 1
- Contact Plating
- Gold, Tin
- Depth Behind Panel
- 11.00mm
- Index Angle
- 45 °
- Power Rating
- 400mW
- Actuator Type
- Knob
- Actuator Length
- 13.00mm
- Parça Durumu
- Active
- Terminal
- PC Pin
- Current Rating Amps
- 0.4VA AC/DC
- Özellikler
- Sealed - Fully
- JESD-609 Kodu
- e3
- Contact Style
- Non-Shorting
- Panel Cutout Dimensions
- Circular - 6.35mm Dia
- Circuit Per Deck
- SP3T
- Pozisyon Sayısı
- 3
- Operating Force
- 4.079gfm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
