UCZ1E331MCS1GS

Teknik Özellikler

Capacitor Type

ALUMINUM ELECTROLYTIC CAPACITOR

Life Hours

3000 hours

RoHS Durumu

RoHS Compliant

Terminal Kaplaması

Tin/Bismuth (Sn/Bi)

ECCN Kodu

EAR99

Çap

10mm

Uzunluk

10.9mm

Terminal

SMD/SMT

Seri

UCZ

Dielectric Material

ALUMINUM (WET)

Genişlik

10.3mm

Ripple Current Low Frequency

250mA @ 120Hz

Polarization

Polar

Applications

General Purpose

Esr Equivalent Series Resistance

150mOhm @ 100kHz

Kılıf / Paket

Radial, Can - SMD

Boyut / Ölçü

0.394Dia 10.00mm

Terminal Shape

FLAT

JESD-609 Kodu

e6

Ripple Current High Frequency

500mA @ 100kHz

HTS Kodu

8532.22.00

Kurşunsuz Kodu

yes

Ripple Current

500mA

Maks. Oturma Yüksekliği

0.425 10.80mm

Voltage Rated Dc

25V

Dissipation Factor

0.18 %

Nem Hassasiyeti (MSL)

1 (Unlimited)

Montaj Tipi

Surface Mount

Çalışma Sıcaklığı

-40°C~125°C

Terminal Sayısı

2

Kapasitans

330μF

Ambalaj

Tape & Reel (TR)

Parça Durumu

Active

Lifetime Temp

3000 Hrs @ 125°C

Surface Mount Land Size

0.406Lx0.406W 10.30mmx10.30mm

Tolerans

±20%

Leakage Current

3μA

Fabrika Tedarik Süresi

20 Weeks

Size Code

4141
