UCZ1A471MCS1GS

Teknik Özellikler

JESD-609 Kodu

e6

Ripple Current High Frequency

500mA @ 100kHz

Boyut / Ölçü

0.394Dia 10.00mm

Kılıf / Paket

Radial, Can - SMD

Esr Equivalent Series Resistance

150mOhm @ 100kHz

Terminal Shape

FLAT

Kurşunsuz Kodu

yes

HTS Kodu

8532.22.00

Dielectric Material

ALUMINUM (WET)

Genişlik

10.3mm

Seri

UCZ

Tan Delta

0.3

Terminal

SMD/SMT

Polarization

Polar

Applications

General Purpose

Ripple Current Low Frequency

250mA @ 120Hz

Terminal Kaplaması

Tin/Bismuth (Sn/Bi)

Uzunluk

10.9mm

ECCN Kodu

EAR99

Çap

10mm

Capacitor Type

ALUMINUM ELECTROLYTIC CAPACITOR

RoHS Durumu

RoHS Compliant

Life Hours

3000 hours

Fabrika Tedarik Süresi

20 Weeks

Size Code

4141

Surface Mount Land Size

0.406Lx0.406W 10.30mmx10.30mm

Lifetime Temp

3000 Hrs @ 125°C

Parça Durumu

Active

Ambalaj

Tape & Reel (TR)

Tolerans

±20%

Leakage Current

3μA

Çalışma Sıcaklığı

-40°C~125°C

Kapasitans

470μF

Terminal Sayısı

2

Voltage Rated Dc

10V

Maks. Oturma Yüksekliği

0.425 10.80mm

Ripple Current

500mA

Dissipation Factor

0.3 %

Montaj Tipi

Surface Mount

Nem Hassasiyeti (MSL)

1 (Unlimited)
