Adet bazlı fiyat
- 1+ adet$0.47
- 10+ adet$0.44
- 100+ adet$0.41
- 500+ adet$0.39
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Terminal
- Radial
- Çalışma Sıcaklığı
- -55°C~105°C
- Ripple Current High Frequency
- 5.6A @ 100kHz
- Çap
- 6.3mm
- JESD-609 Kodu
- e3
- Maks. Oturma Yüksekliği
- 0.354 9.00mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Life Hours
- 2000 hours
- Dielectric Material
- ALUMINUM (DRY/SOLID)
- Montaj Tipi
- Through Hole
- Fabrika Tedarik Süresi
- 18 Weeks
- Kapasitans
- 1200μF
- Lead Pitch
- 2.4892mm
- Reach Svhc
- No SVHC
- Parça Durumu
- Active
- Yükseklik
- 8mm
- Kılıf / Paket
- Radial, Can
- HTS Kodu
- 8532.22.00
- Seri
- FPCAP, RS8
- Ambalaj
- Tape & Box (TB)
- Ripple Current
- 5.6A
- Lead Spacing
- 0.098 2.50mm
- Terminal Kaplaması
- Tin (Sn)
- ECCN Kodu
- EAR99
- Leakage Current
- 750μA
- Montaj
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Lifetime Temp
- 2000 Hrs @ 105°C
- Yayın Yılı
- 2013
- Terminal Sayısı
- 2
- Tolerans
- ±20%
- Tip
- Polymer
- Boyut / Ölçü
- 0.248Dia 6.30mm
- Dissipation Factor
- 0.1 %
- Kurşunsuz Kodu
- yes
- Voltage Rated Dc
- 2.5V
- Esr Equivalent Series Resistance
- 7mOhm
- Ripple Current Low Frequency
- 560mA @ 120Hz
- Applications
- General Purpose
