Adet bazlı fiyat
- 1+ adet$0.78
- 10+ adet$0.74
- 100+ adet$0.70
- 500+ adet$0.66
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Lifetime Temp
- 2000 Hrs @ 105°C
- Applications
- General Purpose
- Terminal Kaplaması
- Tin (Sn)
- ECCN Kodu
- EAR99
- Maks. Oturma Yüksekliği
- 0.236 6.00mm
- Boyut / Ölçü
- 0.248Dia 6.30mm
- Yayın Yılı
- 2015
- Ripple Current Low Frequency
- 250mA @ 120Hz
- Kapasitans
- 150μF
- Ambalaj
- Tape & Box (TB)
- Esr Equivalent Series Resistance
- 25mOhm
- Tan Delta
- 0.1
- Tip
- Polymer
- Lead Spacing
- 0.098 2.50mm
- Terminal Shape
- WIRE
- Tolerans
- ±20%
- Polarity
- POLARIZED
- Ripple Current
- 2.5A
- Terminal
- Radial
- Kurşunsuz Kodu
- yes
- Terminal Sayısı
- 2
- Montaj
- Through Hole
- Ripple Current High Frequency
- 2.5A @ 100kHz
- Parça Durumu
- Active
- Dissipation Factor
- 0.1 %
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Life Hours
- 2000 hours
- Montaj Tipi
- Through Hole
- Voltage Rated Dc
- 10V
- HTS Kodu
- 8532.22.00
- JESD-609 Kodu
- e3
- Fabrika Tedarik Süresi
- 18 Weeks
- Çalışma Sıcaklığı
- -55°C~105°C
- Lead Pitch
- 2.4892mm
- Seri
- FPCAP, RS6
- Kılıf / Paket
- Radial, Can
- Leakage Current
- 450μA
