Adet bazlı fiyat
- 1+ adet$0.95
- 10+ adet$0.90
- 100+ adet$0.85
- 500+ adet$0.80
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Yükseklik
- 12.5mm
- Leakage Current
- 937.5μA
- Maks. Oturma Yüksekliği
- 0.492 12.50mm
- Ripple Current
- 7.22A
- Ripple Current Low Frequency
- 722mA @ 120Hz
- Boyut / Ölçü
- 0.394Dia 10.00mm
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2009
- Esr Equivalent Series Resistance
- 5mOhm
- Terminal Kaplaması
- Tin (Sn)
- Ripple Current High Frequency
- 7.22A @ 100kHz
- Tolerans
- ±20%
- Lead Pitch
- 5.0038mm
- Kılıf / Paket
- Radial, Can
- Packing Method
- Box
- Montaj
- Through Hole
- Kapasitans
- 1500μF
- Fabrika Tedarik Süresi
- 18 Weeks
- Montaj Tipi
- Through Hole
- Polarity
- POLARIZED
- Seri
- FPCAP, RR5
- Terminal
- Radial
- Lifetime Temp
- 2000 Hrs @ 105°C
- Life Hours
- 2000 hours
- JESD-609 Kodu
- e3
- HTS Kodu
- 8532.22.00
- Ambalaj
- Bulk
- Çalışma Sıcaklığı
- -55°C~105°C
- Çap
- 10mm
- Lead Spacing
- 0.197 5.00mm
- Parça Durumu
- Active
- Terminal Sayısı
- 2
- Dissipation Factor
- 0.15 %
- RoHS Durumu
- ROHS3 Compliant
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Applications
- General Purpose
- Tip
- Polymer
- Voltage Rated Dc
- 2.5V
- Dielectric Material
- ALUMINUM
