Adet bazlı fiyat
- 1+ adet$0.37
- 10+ adet$0.35
- 100+ adet$0.33
- 500+ adet$0.31
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Lead Pitch
- 3.5mm
- Kılıf / Paket
- Radial, Can
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2009
- Tolerans
- ±20%
- Ripple Current High Frequency
- 6.63A @ 100kHz
- Esr Equivalent Series Resistance
- 5mOhm
- Terminal Kaplaması
- Tin (Sn)
- Reach Svhc
- No SVHC
- Ripple Current Low Frequency
- 663mA @ 120Hz
- Boyut / Ölçü
- 0.315Dia 8.00mm
- Leakage Current
- 625μA
- Maks. Oturma Yüksekliği
- 0.453 11.50mm
- Yükseklik
- 11.5mm
- Ripple Current
- 6.63A
- Tip
- Polymer
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Applications
- General Purpose
- ECCN Kodu
- EAR99
- Dielectric Material
- ALUMINUM
- Voltage Rated Dc
- 2.5V
- Lead Spacing
- 0.138 3.50mm
- Parça Durumu
- Active
- Terminal Sayısı
- 2
- RoHS Durumu
- ROHS3 Compliant
- Dissipation Factor
- 0.15 %
- Lifetime Temp
- 2000 Hrs @ 105°C
- Life Hours
- 2000 hours
- JESD-609 Kodu
- e3
- HTS Kodu
- 8532.22.00
- Seri
- FPCAP, RR5
- Terminal
- Radial
- Çalışma Sıcaklığı
- -55°C~105°C
- Çap
- 8mm
- Ambalaj
- Bulk
- Packing Method
- Box
- Montaj
- Through Hole
- Montaj Tipi
- Through Hole
- Polarity
- POLARIZED
- Fabrika Tedarik Süresi
- 18 Weeks
