Adet bazlı fiyat
- 1+ adet$0.50
- 10+ adet$0.47
- 100+ adet$0.44
- 500+ adet$0.42
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- RoHS Durumu
- ROHS3 Compliant
- Montaj Tipi
- Through Hole
- Terminal Kaplaması
- Tin (Sn)
- Terminal Shape
- WIRE
- Seri
- FPCAP, RHT
- Voltage Rated Dc
- 6.3V
- Çap
- 10mm
- Kılıf / Paket
- Radial, Can
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2009
- Fabrika Tedarik Süresi
- 18 Weeks
- Ripple Current High Frequency
- 5.45A @ 100kHz
- HTS Kodu
- 8532.22.00
- Tolerans
- ±20%
- Kapasitans
- 820μF
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Maks. Oturma Yüksekliği
- 0.492 12.50mm
- Tip
- Polymer
- Lifetime Temp
- 1000 Hrs @ 125°C
- Boyut / Ölçü
- 0.394Dia 10.00mm
- Dielectric Material
- ALUMINUM
- Terminal
- Radial
- Dissipation Factor
- 0.12 %
- Ripple Current
- 5.45A
- Polarity
- POLARIZED
- Leakage Current
- 1.0332mA
- Montaj
- Through Hole
- Lead Pitch
- 5.0038mm
- JESD-609 Kodu
- e3
- Kurşunsuz Kodu
- yes
- Terminal Sayısı
- 2
- Yükseklik
- 12.5mm
- Life Hours
- 1000 hours
- Lead Spacing
- 0.197 5.00mm
- Esr Equivalent Series Resistance
- 12mOhm
- Çalışma Sıcaklığı
- -55°C~125°C
- Ripple Current Low Frequency
- 545mA @ 120Hz
- Ambalaj
- Bulk
- Applications
- General Purpose
