LM5100AMR

Teknik Özellikler

Interface Ic Type

HALF BRIDGE BASED MOSFET DRIVER

High Side Driver

YES

Seated Heightmax

1.68 mm

Supply Voltagemax

14 V

Terminal Pozisyonu

DUAL

Package Equivalence Code

SOP8,.25

REACH Uyumluluk Kodu

unknown

Temperature Grade

AUTOMOTIVE

Pin Sayısı

8

Ihs Manufacturer

TEXAS INSTRUMENTS INC

Genişlik

3.9 mm

Part Life Cycle Code

Obsolete

Operating Temperaturemin

-40 °C

Terminal Adımı

1.27 mm

Output Peak Current Limitnom

3 A

Package Shape

RECTANGULAR

ECCN Kodu

EAR99

Uzunluk

4.9 mm

Pin Sayısı

8

HTS Kodu

8542.39.00.01

Terminal Formu

GULL WING

Package Code

HLSOP

Turnon Time

0.045 µs

Operating Temperaturemax

125 °C

Supply Voltagenom

12 V

Number Of Terminals

8

Part Package Code

SOIC

Yüzey Montaj

YES

Fonksiyon Sayısı

1

Jesd30 Code

R-PDSO-G8

Supply Voltagemin

9 V

Package Style

SMALL OUTLINE, HEAT SINK/SLUG, LOW PROFILE

Package Description

HLSOP,

RoHS

Non-Compliant

Package Body Material

PLASTIC/EPOXY

Turnoff Time

0.045 µs
