Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 6 Weeks
- Radyasyon Dayanımı
- No
- Contact Resistance
- 15mOhm
- Wire Gauge Min
- 26 AWG
- Terminal
- IDC
- JESD-609 Kodu
- e4
- Iec Conformance
- NO
- Plating Thickness
- 30μin
- Connector Type
- IDC, Receptacle, Socket
- Akım Değeri
- 1.2A
- Lead Pitch
- 1.27mm
- Body Length Or Diameter
- 0.999 inch
- HTS Kodu
- 8536.69.40.40
- Dielectric Withstanding Voltage
- 750VAC V
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Wirecable Type
- Ribbon
- Reliability
- COMMERCIAL
- Housing Material
- Polyester
- Total Number Of Contacts
- 18
- Reach Svhc
- Unknown
- Gender
- Receptacle
- Mil Conformance
- NO
- Parça Durumu
- Active
- Polarization Key
- POLARIZED HOUSING
- Kurşunsuz
- Lead Free
- Wire Gauge Max
- 28 AWG
- Ul Flammability Code
- 94V-0
- Option
- GENERAL PURPOSE
- ECCN Kodu
- EAR99
- Contact Materials
- Bronze
- Din Conformance
- NO
- Nominal Gerilim
- 250V
- Montaj
- Cable, Free Hanging
- Orientation
- Right Angle
- Reference Standard
- UL, CSA
- Min. Çalışma Sıcaklığı
- -40°C
- Bodyshell Style
- PLUG
- Insulation Resistance
- 1000000000Ohm
- Pitch
- 1.27mm
- Additional Feature
- PICOFLEX, LOW PROFILE, POLARIZED
