90143-0040

Teknik Özellikler

Min. Çalışma Sıcaklığı

-55°C

Parça Durumu

Active

Additional Feature

C-GRID III, POLARIZED

Pitch

2.54mm

Contact Finish Mating

NOT SPECIFIED

Housing Material

PPO

Mil Conformance

NO

Insulation Resistance

1000000000Ohm

Maks. Çalışma Sıcaklığı

105°C

Option

GENERAL PURPOSE

Orientation

Straight

Connector Type

Receptacle, Socket

Contact Pattern

RECTANGULAR

Contact Style

SQ PIN-SKT

RoHS Durumu

RoHS Compliant

Kurşunsuz

Lead Free

Yayın Yılı

2008

Ul Flammability Code

94V-1

Body Depth

0.6 inch

Mixed Contacts

NO

Number Of Contacts

40

Row Spacing Mating

2.54 mm

Dielectric Withstanding Voltage

1000VDC V

Contact Materials

NOT SPECIFIED

Ambalaj

Bulk

Kurşunsuz Kodu

yes

Terminal

Crimp

Iec Conformance

NO

Akım Değeri

3A

Rated Current Signal

3A

Montaj

Cable, Free Hanging

Reliability

COMMERCIAL

ECCN Kodu

EAR99

Glow Wire Compliant

Non-compliant

Fabrika Tedarik Süresi

12 Weeks

Contact Gender

Female

Filter Feature

NO

Bodyshell Style

PLUG

Din Conformance

NO

Mating Information

MULTIPLE MATING PARTS AVAILABLE
