90130-3250

Teknik Özellikler

Number Of Circuits

50

Terminal

Solder

Reference Standard

UL

Kurşunsuz Kodu

yes

Montaj Tipi

BOARD

Filter Feature

NO

Reliability

COMMERCIAL

Rated Current Signal

3A

Gender

Male

Plating Thickness

15μin

Renk

Black

Din Conformance

NO

HTS Kodu

8536.69.40.40

Pcb Contact Pattern

RECTANGULAR

Housing Material

Polyester

Contact Finish Mating

NOT SPECIFIED

Additional Feature

SHROUDED

Max Voltage Rating Ac

350V

Insertion Forcemax

1.0008 N

Parça Durumu

Active

Orientation

Right Angle

Option

GENERAL PURPOSE

Maks. Çalışma Sıcaklığı

125°C

Yayın Yılı

2008

Body Depth

0.515 inch

Ul Flammability Code

94V-0

Contact Style

SQ PIN-SKT

RoHS Durumu

RoHS Compliant

Dielectric Withstanding Voltage

700VAC V

Contact Materials

Brass

Total Number Of Contacts

50

Body Breadth

0.384 inch

ECCN Kodu

EAR99

Mating Contact Row Spacing

0.1 inch

Bodyshell Style

RECEPTACLE

Iec Conformance

NO

Sıra Sayısı

2

Mounting Option1

LOCKING

Uzunluk

66.22mm

Number Of Conductors

ONE
