90130-1140

Teknik Özellikler

Insulation Resistance

5000000000Ohm

Bodyshell Style

RECEPTACLE

Yayın Yılı

2009

Total Number Of Contacts

40

Glow Wire Compliant

Non-compliant

Renk

Black

Parça Durumu

Active

Terminal

Solder

Contact Pattern

RECTANGULAR

Ul Flammability Code

94V-0

Connector Type

Male Pin

Filter Feature

NO

Mil Conformance

NO

Maks. Çalışma Sıcaklığı

125°C

Body Breadth

0.384 inch

Number Of Conductors

ONE

Akım Değeri

3A

Pcb Contact Pattern

RECTANGULAR

Plating Thickness

118μin

Max Voltage Rating Dc

350.35kV

Rated Current Signal

3A

Contact Plating

Tin

Reach Svhc

No SVHC

Min. Çalışma Sıcaklığı

-55°C

Mixed Contacts

NO

Contact Style

SQ PIN-SKT

Contact Lengthmating

6.7564mm

Pitch

2.54mm

Additional Feature

C-GRID, SHROUDED

Radyasyon Dayanımı

No

Body Depth

0.515 inch

Sıra Sayısı

2

Orientation

Vertical

Option

GENERAL PURPOSE

Durability

500 Cycles

Dielectric Withstanding Voltage

700VAC V

Pozisyon Sayısı

40

RoHS Durumu

RoHS Compliant

Row Spacing Mating

2.54 mm

Contact Materials

Brass
