90121-0800

Teknik Özellikler

Iec Conformance

NO

Reliability

COMMERCIAL

Contact Materials

Brass

RoHS Durumu

RoHS Compliant

Number Of Contacts

40

Dielectric Withstanding Voltage

350VDC V

Orientation

Right Angle

Option

GENERAL PURPOSE

Body Length Or Diameter

4 inch

Gender

Male

Lead Pitch

2.54mm

Fabrika Tedarik Süresi

13 Weeks

Number Of Pcb Rows

1

Kurşunsuz

Lead Free

Nominal Gerilim

350V

Montaj

Through Hole

Din Conformance

NO

Insertion Forcemax

.973 N

Kurşunsuz Kodu

yes

Housing Material

Polyester

ECCN Kodu

EAR99

Reference Standard

UL

Filter Feature

NO

Mil Conformance

NO

Maks. Çalışma Sıcaklığı

125°C

Connector Type

Male Pin

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Ul Flammability Code

94V-0

Contact Pattern

RECTANGULAR

Terminal

Solder

Akım Değeri

3A

Number Of Conductors

ONE

Glow Wire Compliant

Non-compliant

Yayın Yılı

2008

Bodyshell Style

RECEPTACLE

Insulation Resistance

5000000000Ohm

Number Of Circuits

36

Ambalaj

Bulk

Renk

Black

JESD-609 Kodu

e3
