Teknik Özellikler
- Din Conformance
- NO
- Reliability
- COMMERCIAL
- Kurşunsuz
- Contains Lead
- Min. Çalışma Sıcaklığı
- -20°C
- Maks. Çalışma Sıcaklığı
- 85°C
- Contact Plating
- Gold
- Durability
- 100 Cycles
- RoHS Durumu
- RoHS Compliant
- Pozisyon Sayısı
- 20
- Contact Resistance
- 30mOhm
- Pitch
- 2mm
- Iec Conformance
- NO
- Option
- GENERAL PURPOSE
- Kurşunsuz Kodu
- yes
- Montaj
- Cable, Free Hanging
- Connector Type
- IDC, Receptacle, Socket
- Sıra Sayısı
- 2
- Total Number Of Contacts
- 20
- Rated Current Signal
- 1A
- Mixed Contacts
- NO
- Body Depth
- 0.449 inch
- Contact Style
- SQ PIN-SKT
- Plating Thickness
- 15μin
- Contact Pattern
- RECTANGULAR
- Terminal
- IDC
- Ul Flammability Code
- 94V-0
- Nominal Gerilim
- 125V
- Dielectric Withstanding Voltage
- 500VAC V
- Housing Material
- Polyester
- Parça Durumu
- Active
- Orientation
- Right Angle
- Wirecable Gauge
- 28 AWG
- Akım Değeri
- 1A
- Glow Wire Compliant
- Non-compliant
- Renk
- Black
- Gender
- Receptacle
- JESD-609 Kodu
- e3
- Filter Feature
- NO
- Contact Materials
- Copper
- Contact Gender
- Female
