Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Nominal Gerilim
- 125V
- Dielectric Withstanding Voltage
- 500VAC V
- Parça Durumu
- Active
- Housing Material
- Polyester
- Wirecable Gauge
- 28 AWG
- Orientation
- Right Angle
- Plating Thickness
- 15μin
- Contact Style
- SQ PIN-SKT
- Contact Pattern
- RECTANGULAR
- Terminal
- IDC
- Ul Flammability Code
- 94V-0
- Reference Standard
- UL, CSA
- Row Spacing Mating
- 2.0066 mm
- Wirecable Type
- Ribbon
- Lead Pitch
- 2mm
- Insulation Resistance
- 5000000000Ohm
- Fabrika Tedarik Süresi
- 9 Weeks
- Gender
- Receptacle
- Renk
- Black
- Glow Wire Compliant
- Non-compliant
- Akım Değeri
- 1A
- Contact Gender
- Female
- Yayın Yılı
- 2011
- JESD-609 Kodu
- e3
- Filter Feature
- NO
- Contact Materials
- Copper
- Additional Feature
- MILLI-GRID, POLARIZED
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Polarization Key
- POLARIZED HOUSING
- Mil Conformance
- NO
- Insertion Forcemax
- 1.946 N
- Durability
- 100 Cycles
- RoHS Durumu
- RoHS Compliant
- Contact Resistance
- 30mOhm
- Pozisyon Sayısı
- 16
- Pitch
- 2mm
- Maks. Çalışma Sıcaklığı
- 85°C
- Din Conformance
- NO
- Min. Çalışma Sıcaklığı
- -20°C
- Reliability
- COMMERCIAL
