Teknik Özellikler
- Fabrika Tedarik Süresi
- 9 Weeks
- Insulation Resistance
- 5000000000Ohm
- Body Length Or Diameter
- 0.734 inch
- Lead Pitch
- 2mm
- Wirecable Type
- Ribbon
- Row Spacing Mating
- 2.0066 mm
- Reference Standard
- UL, CSA
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Polarization Key
- POLARIZED HOUSING
- Mil Conformance
- NO
- Insertion Forcemax
- 1.946 N
- Additional Feature
- MILLI-GRID, POLARIZED
- Yayın Yılı
- 2011
- Contact Gender
- Female
- Contact Materials
- Copper
- Filter Feature
- NO
- JESD-609 Kodu
- e3
- Glow Wire Compliant
- Non-compliant
- Renk
- Black
- Gender
- Receptacle
- Akım Değeri
- 1A
- Wirecable Gauge
- 28 AWG
- Orientation
- Right Angle
- Parça Durumu
- Active
- Housing Material
- Polyester
- Dielectric Withstanding Voltage
- 500VAC V
- Nominal Gerilim
- 125V
- Ul Flammability Code
- 94V-0
- Terminal
- IDT
- Contact Pattern
- RECTANGULAR
- Plating Thickness
- 15μin
- Contact Style
- SQ PIN-SKT
- Body Depth
- 0.449 inch
- Mixed Contacts
- NO
- Rated Current Signal
- 1A
- Total Number Of Contacts
- 12
- Sıra Sayısı
- 2
- Connector Type
- IDC, Receptacle, Socket
- Montaj
- Cable, Free Hanging
- Kurşunsuz Kodu
- yes
