70553-0043

Teknik Özellikler

Pozisyon Sayısı

9

Material

Brass

Flammability Rating

UL94 V-0

Reference Standard

UL

Pcb Contact Pattern

RECTANGULAR

Total Number Of Contacts

9

Pitch

2.54mm

Iec Conformance

NO

Orientation

Right Angle

Voltage Rated Dc

250V

Number Of Conductors

ONE

Body Breadth

0.275 inch

Kurşunsuz Kodu

yes

Terminal

Solder

Min. Çalışma Sıcaklığı

-40°C

Montaj

Through Hole

Glow Wire Compliant

Non-compliant

Contact Pattern

RECTANGULAR

Lead Pitch

2.54mm

Parça Durumu

Active

Akım Değeri

3A

Maks. Çalışma Sıcaklığı

105°C

Additional Feature

LATCHED

Sıra Sayısı

1

Number Of Pcb Rows

1

Body Depth

0.535 inch

Mixed Contacts

NO

Gender

Male

RoHS Durumu

RoHS Compliant

Fabrika Tedarik Süresi

8 Weeks

Reliability

COMMERCIAL

Din Conformance

NO

Connector Type

Male Pin

Option

GENERAL PURPOSE

Contact Lengthmating

6.096mm

Elv

Compliant

JESD-609 Kodu

e3

Bodyshell Style

RECEPTACLE

Housing Material

Thermoplastic

Contact Materials

Bronze
