54550-1094

Teknik Özellikler

Number Of Pcb Rows

1

Lead Pitch

500μm

Body Breadth

0.047 inch

Gender

Female

Additional Feature

ZIF

Mil Conformance

NO

RoHS Durumu

RoHS Compliant

Plating Thickness

40μin

Insertion Forcemax

ZIF N

Sıra Sayısı

1

Filter Feature

NO

Wirecable Type

Straight

Orientation

Right Angle

Durability

20 Cycles

Flammability Rating

UL94 V-0

Kurşunsuz Kodu

yes

Mixed Contacts

NO

Din Conformance

NO

Contact Style

BELLOWED TYPE

Rated Current Signal

0.5A

Yayın Yılı

2011

Depth

5mm

Contact Plating

Tin

Pitch

500μm

Montaj

Surface Mount

Housing Color

Natural

Pcb Contact Pattern

RECTANGULAR

Dielectric Withstanding Voltage

250VAC V

Uzunluk

10.2mm

Actuator Material

Polyphenylene

Withdrawl Forcemin

ZIF N

Contact Pattern

RECTANGULAR

Contact Materials

Bronze

Min. Çalışma Sıcaklığı

-20°C

Insulation Resistance

50000000Ohm

Radyasyon Dayanımı

No

Iec Conformance

NO

Terminal

Solder

Housing Material

Polymer

Contact Resistance

40mOhm
