Adet bazlı fiyat
- 1+ adet$0.62
- 10+ adet$0.59
- 100+ adet$0.56
- 500+ adet$0.52
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Çalışma Sıcaklığı
- -40°C~105°C
- Ffc Fcb Thickness
- 0.30mm
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Montaj Tipi
- Surface Mount, Right Angle
- Actuatorcolor
- Black
- Flat Flex Type
- FFC, FPC
- Yayın Yılı
- 2015
- Current Rating Amps
- 0.5A
- Pozisyon Sayısı
- 12
- Ambalaj
- Tape & Reel (TR)
- Housing Color
- Beige
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Seri
- Easy-On FD19 505110
- Pitch
- 0.020 0.50mm
- Height Above Board
- 0.075 1.90mm
- Contact Finish
- Gold
- Nominal Gerilim
- 50V
- Cable End Type
- Tabbed, Tapered
- Contact Finish Thickness
- 1.97μin 0.050μm
- Locking Feature
- Flip Lock, Backlock
- Contact Materials
- Phosphor Bronze
- Mating Cycles
- 25
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 17 Weeks
