Adet bazlı fiyat
- 1+ adet$2.58
- 10+ adet$2.43
- 100+ adet$2.30
- 500+ adet$2.17
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Sıra Sayısı
- 1
- Ambalaj
- Tape & Reel (TR)
- Height Above Board
- 0.148 3.75mm
- Flammability Rating
- UL94 V-0
- Montaj
- Surface Mount
- Material Flammability Rating
- UL94 V-0
- Orientation
- Right Angle
- Ffc Fcb Thickness
- 0.33mm
- Housing Color
- Black
- Montaj Tipi
- Surface Mount, Right Angle
- Kurşunsuz Kodu
- yes
- Çalışma Sıcaklığı
- -20°C~85°C
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flat Flex Type
- FFC
- Yükseklik
- 3.75mm
- Parça Durumu
- Active
- Yayın Yılı
- 2015
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Copper Alloy
- Özellikler
- Solder Retention
- Reliability
- COMMERCIAL
- Pcb Contact Pattern
- RECTANGULAR
- Gender
- Female
- Body Depth
- 0.23 inch
- Contact Finish
- Gold
- Number Of Pcb Rows
- 1
- Mating Cycles
- 20
- Fabrika Tedarik Süresi
- 17 Weeks
- Contact Pattern
- RECTANGULAR
- Seri
- 503908
- Number Of Contacts
- 51
- Akım Değeri
- 500mA
- Terminal
- Solder
- Current Rating Amps
- 0.5A
- Pitch
- 0.020 0.50mm
- Cable End Type
- Tabbed
- Nominal Gerilim
- 50V
- Contact Finish Thickness
- 3.94μin 0.10μm
- Contact Style
- BELLOWED TYPE
